CHIP AND IP PROCESS MIGRATION

Process migration is key to extending the lifespan and optimizing the business value of existing chip designs and semiconductor intellectual property (IP). And as part of the chip or IP design best practices, it dramatically lowers the risk of supply chain disruption, a part of a good global business risk management process.

The benefits of process migration are straightforward, but the task is rather complex. Business goals must be clear, technology impacts/choices aligned to those goals. Once a path forward is established, companies must have the expertise and resources available to migrate and validate efficiently.

Capgemini engineering provides a global and fully automated Validation & Verification (V&V) platform and a Global Training Center, which provides an entire training journey solution to upskill and train engineers. Our services range from function development to complete turnkey projects as an integration partner.

Capgemini is the world leader in semiconductor ER&D services. We are ranked #1 in semiconductor ER&D services for the last 5 years. We are a trusted partner to 8 of the industry’s top 10 leaders. And we are the world’s largest VLSI ER&D workforce.
